特點
完全密封的定子繞組
155C 內部繞組溫度持續能力
PTC 熱敏電阻 (雪崩式) 過載保護
稀土釹鐵硼磁體
轉子磁體的自動防故障頻帶，兼容RoHS
UL, CE認證
可定制的轉子輪轂尺寸
優勢
和負載直接連接，消除了減速機、同步帶和滑輪
零齒隙提供了更好的系統性能
消除了機器連接設備，降低了機器的整體尺寸
內置式電機使機器更為緊湊
大量的標準電機備選，并提供定制化服務，助您更快，更經濟的研發您的機器
| KBM(S)機框尺寸 | 外徑 | 通空直徑 | 連續失速轉矩 | 峰值失速轉矩 | 額定輸出功率 |
| KBM(S)-10 | 59.96 mm | 16.01 mm | 0.49 - 1.45 Nm | 1.17 - 4.91 Nm | 0.9 - 3.0 KW |
| KBM(S)-14 | 74.9 6mm | 20.01 mm | 1.22 - 2.92 Nm | 3.28 - 10.50 Nm | 0.9 - 3.0 KW |
| KBM(S)-17 | 84.96 mm | 30.01 mm | 2.06 - 6.20 Nm | 5.95 - 24.00 Nm | 0.9 - 3.0 KW |
| KBM(S)-25 | 109.96 mm | 50.01 mm | 4.85 - 11.1 Nm | 14.4 - 54.8 Nm | 0.9 - 3.0 KW |
| KBM(S)-35 | 139.96 mm | 65.01 mm | 12.4 - 25.9 Nm | 40.8 - 93.0 Nm | 0.9 - 3.0 KW |
| KBM(S)-45 | 189.96 mm | 85.02 mm | 29.7 - 54.6 Nm | 119 - 218 Nm | 0.9 - 3.0 KW |
| KBM(S)-43 | 159.78 mm | 76.28 mm | 6.11 - 44.2 Nm | 18.0 - 153 Nm | 0.9 - 3.0 KW |
| KBM(S)-57 | 202.90 mm | 104.17 mm | 18.8 - 109 Nm | 60 - 441 Nm | 0.9 - 3.0 KW |
| KBM(S)-60 | 229.85 mm | 105.05 mm | 29.4 - 154 Nm | 69.1 - 393 Nm | 8.4 - 20.1 KW |
| KBM(S)-79 | 259.63 mm | 152.43 mm | 43.5 - 222 Nm | 152 - 1075 Nm | 8.4 - 20.1 KW |
| KBM(S)-88 | 331.46 mm | 155.01 mm | 102 - 545 Nm | 197 - 1200 Nm | 8.4 - 20.1 KW |
| KBM(S)-118 | 361.11 mm | 225.04 mm | 172 - 672 Nm | 498 - 2400 Nm | 8.4 - 20.1 KW |
| KBM(S)-163 | 605.0 mm | 315.50 mm | 764 - 1329 Nm | 1966 - 3932 Nm | 8.4 - 20.1 KW |
| KBM(S)-260 | 850.0 mm | 557.85 mm | 1932 - 3445 Nm | 6494 - 12812 Nm | 8.4 - 20.1 KW |
